Description
View product specs: Click Here to View
View SDS:
Availability: 1‐gallon (3.785 liters), 5‐gallon pail (18.9 liters), 55‐gallon drum (208 liters) & 275‐gallon IBC Tote (1,040 liters)
Product Equivalent: DOW CORNING 200® FLUID, 50 CS, DOW CORNING 200®, FLUID 100 CS, DOW CORNING 200®, FLUID 200 CS, DOW CORNING 200®, FLUID 350 CS, DOW CORNING 200®, FLUID 500 CS, DOW CORNING 200®, FLUID 1,000 CS, XIAMETER® PMX‐200 SILICONE FLUID, 50CST, XIAMETER® PMX‐200 SILICONE FLUID, 100CST, XIAMETER® PMX‐200 SILICONE FLUID, 200CST, XIAMETER® PMX‐200 SILICONE FLUID, 350CST, XIAMETER® PMX‐200 SILICONE FLUID, 500CST, XIAMETER® PMX‐200 SILICONE FLUID, 1,000CST, GE SF96‐50, GE SF96‐100, GE SF96‐350, GE SF96‐500, GE SF96‐1,000, ELEMENT 14® PDMS 50, ELEMENT 14® PDMS 100, ELEMENT 14® PDMS 350, ELEMENT 14® PDMS 500, ELEMENT 14® PDMS 1000, WACKER® AK 50, WACKER® AK 100, WACKER® AK 350, WACKER® AK 500, WACKER® AK 1000, RHODORSIL® 47 V 50, RHODORSIL® 47 V 100, RHODORSIL® 47 V 350, RHODORSIL® 47 V 500, RHODORSIL® 47 V 1000, BLUESILTM 47 V 50, BLUESILTM 47 V 50, BLUESILTM 47 V 50, BLUESILTM 47 V 100, BLUESILTM 47 V 350, BUESILTM 47 V 500, BLUESILTM 47 V 1000, SHINETSU DM‐FLUID‐50CS, SHINETSU DM‐FLUID‐100CS, SHINETSU DM‐FLUID‐ 350CS, SHINETSU DM‐FLUID‐ 500CS, SHINETSU DM‐FLUID‐1,000CS™
Medium Viscosity Silicone Fluids are widely used in Flow Control, Temperature Control and Motion Control technologies. They are especially advantageous for instruments, gauges and devices that are subject to extreme temperatures and high pressures.
For laboratory bath fluids / heat transfer fluids applications, the PSF‐50cSt and PSF‐100cSt are excellent choices due to their wide service temperature range, low viscosity change at temperature and high dielectric strength. See also Low Temperature Silicone Bath Fluids and Low Temperature Silicone Heat Transfer Fluids.
The refractive index values of Medium Viscosity Pure Silicone Fluids make them widely used in Optics research, LED technologies & Sensor technologies.
Pure Silicone Fluids possess excellent lubricity and are used to lubricate a wide range of rubber & plastic parts including: O‐rings, gaskets, rubber seals, grommets, rubber hoses, rubber cables…
Product Data:
Viscosity (cSt) | Specific Gravity | Refractive Index | Pour Point | Flash Point (open cup) | V.T.C | Thermal Expansion (cc/cc °C) | Thermal Conductivity g/cal/cm/sec °C |
---|---|---|---|---|---|---|---|
50 | 0.960 | 1.402 | -55°C | 285°C | 0.59 | 0.00106 | 0.00036 |
100 | 0.966 | 1.4030 | -55°C | 315°C | 0.60 | 0.00096 | 0.00037 |
200 | 0.968 | 1.4031 | -50°C | 315°C | 0.60 | 0.000960 | 0.00037 |
350 | 0.970 | 1.4032 | -50°C | 315°C | 0.60 | 0.00096 | 0.00037 |
500 | 0.971 | 1.4033 | -50°C | 315°C | 0.60 | 0.00096 | 0.00038 |
1,000 | 0.971 | 1.4035 | -50°C | 315°C | 0.61 | 0.00096 | 0.00038 |
Properties:
- Medium Viscosity PDMS Silicone Oils
- High Flash Points
- Low pour points (as low as ‐55°C)
- Wide Service Temperature Range
- Low viscosity change at temperature (low VTC)
- RI Matching Fluids for RI Values between 1.402 to 1.4035
- High Dielectric Strength
- High Damping Action
- Stable under high rates of pressure
- Stable under high rates of shear
- Newtonian behavior under shear
- Excellent Lubricity
Applications Include:
- Laboratory Bath Fluids
- Heat Transfer Fluids
- Dielectric Fluids
- Damping Fluids
- ORC Turbo Generator Fluids
- Hydraulic Fluids
- High Pressure Fluid
- Flow Control Fluid
- Refractive Index Matching Fluids
- RI Matching Fluids for LED and Optics
- Low Dielectric Constant Fluids for Photonics
- VOC Exempt Fluids for Renewable Energies
- Silicone Lubricants for Plastic Parts
- Silicone Lubricants for Rubber Parts
- Calibration Fluid
- Fluid for Touch Screen Technology
Industries & Fields of Research include: R&D, Education, Defense, Oil & Gas Exploration, Energy, Aviation, Aerospace, Life Sciences, Renewable Energies, Turbine Technology, Wind Power Technology, Temperature Control Technologies, Geothermal, Solar Industry, Sensor Technology, Geosciences, Electronics, Environmental, Electrical Testing, Optics, LED, Photonics, MEMS Technology, Refractive Index Matching Digital Display Technology, Flow Control, Flow Meters, Deep Sea / Subsea Technologies, Dielectric Fluids for Wire & Cable, Deepwater, ROV Technologies, Laser Technology Research, Earth & Atmospheric Sciences, Seismic Research, Oceanography Research, Physical Sciences, Chemical Engineering, Mechanical Engineering, 3D Printing Technology, Plasma Research, LCD Technologies, Polymer Research, Computer Engineering Research, Robotics Research, Plastic Manufacturing, Rubber Manufacturing, Hydraulics, Nanotechnology Research, Geothermal, Fuel Cell Technology, Hydrophobic Coatings, Lighting Systems, Seismology, Aeronautics, Pipe & Tubing Systems, Printing Industry, Industrial Cleaning, Touch Screen Technology, Fiber Optics, Touch Monitor Technology, Touch Screen Technology, Temperature and Process Controllers
See also Medium Temperature Bath Fluids and Medium Temperature Heat Transfer Fluid.
Federal Specs Met: meet Federal Specification VV‐D‐1078 “SILICONE AS DAMPING FLUID” and are used in a wide range of military, industrial and avionic gauges, meters, instruments, and monitoring systems.
Meets Requirements Of NSN Codes: NSN 9150‐00‐664‐0047, NSN 9150‐00‐024‐9621, NSN 9150‐00‐664‐0048, NSN 9150‐00‐269‐8246, NSN 9150‐00‐404‐3435, 9150‐00‐584‐3134, NSN 9150‐00‐851‐4257, NSN 9150‐00‐024‐ 9621, NSN 9150‐00‐261‐8327, NSN 9150‐01‐056‐9047, NSN 9150‐00‐024‐9623.
Environmental Low Viscosity Silicone Fluids are exempt from Federal VOC regulations, including California (CARB) and OTC regulations. They are HAP‐free and do not contribute to ozone‐depletion and global warming. In addition, they meet RoHS Compliancy.
